Detcon Model PI-700 is a non-intrusive “Smart” sensor that use photo-ionization detector technology to monitor VOC gases over ranges from 0-10 ppm to 0-5,000 ppm.
There is also a special 0-500 ppb version available. In the PI-700 sensor design, Detcon has successfully converted the sensitive laboratory style PID technology into a rugged, environmentally insensitive, and long-life industrial gas sensor.
The plug-in, field replaceable detector features over-sized gold-plated connections that help prevent corrosion.
The PI-700’s rugged framework includes an electro-polished 316 stainless steel housing with fully encapsulated electronics and dual layer surge protection.
This innovative design virtually eliminates sensor failure due to water ingress, corrosion, vibration, and transient spikes.
A primary feature of the Model PI-700 is embedded intuitive software that simplifies operator interface by guiding the user through routine calibration, configuration, and fault diagnostic functions using a built-in alpha/numeric display.
The Model PI-700 is equipped with standard analog 4-20mA, and Modbus™ RS-485 outputs. Among its unique features is a wireless option that can be used with Detcon’s SmartWireless® product line.
Additional integration options include a Remote Alarm Module (RAM), HART, and Foundation Fieldbus. Detcon’s PID sensors have a long shelf life and are supported by an industry leading warranty.
Failsafe User-Friendly Interface
LED Display (With Antiglare Cover)
Full Text Display Method
Non-intrusive Interface
Auto Zero/Auto Span
Pre-emptive Fault Diagnostics
Environmentally Bulletproof
Electropolished 316SS Construction
100% Epoxy Encapsulated Circuitry
Bulletproof I/O Protection
Water-Proof, Corrosion-Proof, Vibration-Proof
Modular and Serviceable
Modular Design
Plug and Play Components
Quick Thread Release (For Sensor Replacement)
Integral Calibration Port
Sensor Type |
Continuous diffusion/adsorption Photo Ionization Detector (PID) Plug-in replaceable intelligent type (with replacement lamp) |
Sensor Life |
2 years typical |
Measurement Range |
Gas Dependent, ranges as low as 0-10 ppm or as high as 0-5,000ppm (consult Detcon) Special Low Range 0-500 ppb |
Dimensions |
7"H x 2.2" Dia.; 178mmH x 65mm Dia. (sensor assembly only) 11"H x 6.1"W x 3.75"D; 280mmH x 155mmW x 96mmD (with junction box) Mounting holes (J-box) 5.5"; 140mm center to center |
Weight |
2 lbs; 0.907kg (sensor only) 6 lbs; 2.72kg (w/aluminum j-box) 9 lbs; 4.08kg (w/stainless steel j-box) |
Power Input |
11-30 VDC |
